MultimAX 32-70 180

The MultimAX is a highly efficient circulation pump for heating systems as well as cooling and solar applications. In addition to the standard characteristics, you can use the PWM connection to connect the pump to your building services control system.

/Web/Bilder Gross/MultimAX_s_WD.png

Article Number: 7000002244

/Print/CAD_Bilder/CAD/IL00009699.pdf
  • Technical specifications
    Nominal width DN 32
    Flow head H max. 7 m
    Overall length 180 mm
    Threaded connection G 2"
    Operating pressure max. 10 bar
    Media temperature min. -10°C
    Media temperature max. +110°C
    Ambient temperature 0°C bis 70°C
    Net weight 2.2 kg
    EEI ≤0.20 EEI
  • Electrical data
    Voltage 1x230 V
    Frequency 50/60 Hz
    Power P1 2-52 W
    Nominal current 0.04-0.52 A
    Motor protection integrated
  • Included in the scope of delivery
    Heat insulation shell
    Power plug & signal cable (2m)
    AFM seal
Next product in the series
