biral.eu > Products > Domestic hot water > DHW recirculators > CompAX > CompAX BLUE

CompAX 20-1 150 BLUE

The CompAX offers impressively compact proportions, Biral’s simple and clear operating philosophy and a high level of efficiency. Functions such as the flow rate indicator and the deblocking system, make the pump stand out from the crowd.

/Web/Bilder Gross/CompAX_BLUE_s_WD.png

Article Number: 7000001512

/Print/CAD_Bilder/CAD/IL00006376.pdf
  • Technical specifications
    Nominal width DN 20
    Flow head H max. 1 m
    Overall length 150 mm
    Threaded connection G 1 1/4"
    Operating pressure max. 10 bar
    Media temperature min. + 2°C
    Media temperature max. +85°C
    Ambient temperature 0°C bis 40°C
    Water hardness max. at 65 °C 35°fH/20°dH
    Water hardness max. at 85 °C 25°fH/14°dH
    Net weight 1.9 kg
    EEI ECO Design
  • Electrical data
    Voltage 1x230 V
    Frequency 50/60 Hz
    Power P1 2-5 W
    Nominal current 0.03-0.05 A
    Motor protection integriert
  • Included in the scope of delivery
    Heat insulation shell
    Biral Connector
    AFM seal
